taşınabilir handikap rampası

Portable handicap ramp can help wheelchair users solve the problem of platform height difference (such as steps, thresholds and other common scenes in life), assist them to travel smoothly, and are a common barrier-free design. They effectively expand the living range of patients with mobility impairments, reduce the burden on their families, and improve the quality of life of people with mobility impairments.

Selection principles of portable handicap ramps

1. Folding ramps need to select appropriate ramps for different platform height differences, and the recommended slope should not be greater than 1:12;

2. Considering comprehensive safety and other factors, when selecting the length of the ramp, attention should be paid to the ratio between the length of the ramp and the height of the platform, and the angle between them should be less than 15°;

3. After the ramp is selected, special training is required to clarify the precautions during the use of the ramp to further ensure safety.

Selection process of portable handicap ramp

1. The folding ramp should be inspected and measured on site, and the detailed dimensions of the steps should be measured, including the dimensions of the upper and lower platforms and the surrounding areas, to ensure that the ramp has enough space for use;

2. Ramp type selection: Determine the appropriate ramp type according to the specific installation environment;

3. Ramp size confirmation: Determine the length of the ramp according to the height of the platform, the use environment and the comprehensive situation of the user (refer to the ramp angle comparison chart);

4. Ramp installation and debugging: After the ramp is selected, the ramp needs to be installed and debugged on site;

5. Ramp use and guidance: Professional barrier-free engineers will guide users and inform them of the precautions for operation and use to ensure safety during use.

Advantages of HY's portable handicap ramp

1. Widened design, better adapted to various tires, especially large tire types;

2. No installation required, simple, safe, fast deployment of barrier-free transformation;

3. Made of high-strength alloy aluminum, strong, light and durable;

4. Telescopic structure, adjustable length, light and easy to store;

5. Anti-slip hole design on the surface of the product, convenient for water permeability, easy to clean on rainy and snowy days, effectively reducing accidents caused by ramp sliding.

Product parameters

Applicable to manual wheelchairs and electric wheelchairs;

Length: 120/150/180/210/240cm;

Inner width: 25.5cm;

Outer width: 30cm;

Load bearing: 400kg/single side;

Why choose HY?

There are many specifications to choose from. HY can provide various widths according to the different usage scenarios of customers. It can be quickly installed and easy to place, with folding and telescopic functions, easy to carry;

Flexible design, also suitable for countertops with unequal levels at both ends;

Support OEM/ODM customization services, and can provide fast proofing.
